LSRC VS4-10 K10 Scottsdale Body Mounts

Fresh Release!

These body mounts offer a whole new system to the crawler scene with provisions for bolt on rock sliders that can be swapped from one body to the next on multiple platforms that also utilize our body mounts.

The versatility doesn't stop there either; these were designed to have optimal wheel position in the fender arches and clearance in mind for those long leaf conversions, clearanced for leaf brackets and allowing those front shackles to lay all the way back into the frame without interference. The trailing edge of each of these body mounts allows room for multiple styles of rear axle leaf spring hardmounts such as TwistedFabCo.
*Will NOT work with TFC Mega Kits if inner fenders are desired*

Each set of body mounts have recessions in them at each of the link mount locations along the frame rail face and are fitted with brass heat inserts for your body screws for lasting positive engagement and unparalleled strength, while the printed material is engineered to give enough flex when/where needed and will withstand the elements.

-Linked trucks will require a Traxxas JATO Rod End (p/n TRA5525R) on one end of each rear link to achieve the optimal axle position within the wheel well when a 12.3"-12.5" Wheelbase is used (148mm Eye-Eye Lower Link / 141mm Eye-Eye Upper Link).

-Proper orientation is with the LSRC text forward, closest to the front axle… short cutout on frame side should be forward with long cutout towards the rear. The bolt-on slider channel starts 15mm from the front edge of the body mount.
